THORLABS PM100D User Manual

1.2 Ordering Codes and Accessories
1.2 Ordering Codes and Accessories
Order Code Description
PM100D Handheld Power/Energy Meter Console
Photodiode Power Sensors:
Order Code Type Detector Aperture
mm
Wavelength
nm
Power
W
S120C Compact Sensor Si
∅ 9.5
400 - 1100 50n - 50m
S120VC Compact Sensor UV-Si
∅ 9.5
200 - 1100 50n - 50m
S121C Compact Sensor Si
∅ 9.5
400 - 1100 500n - 500m
S122C Compact Sensor Ge
∅ 9.5
700 - 1800 50n - 40m
S130C Slim Sensor
Dual Range
Si
∅ 9.5
400 - 1100 5n - 5m
500n - 500m
S130VC Slim Sensor
Dual Range
UV-Si
∅ 9.5
200 - 1100 5n - 5m
50n - 50m
S132C Slim Sensor
Dual Range
Ge
∅ 9.5
700 - 1800
1200 - 1800
5n - 5m
500n - 500m
S140C Integr. Sphere (1”) Si
∅ 5.0
350 - 1100 1µ - 500m
S144C Integr. Sphere (1”) InGaAs
∅ 5.0
800 - 1700 1µ - 500m
S142C Integr. Sphere (2”) Si
∅ 12
350 - 1100 10µ - 20
S145C Integr. Sphere (2”) InGaAs
∅ 12
800 - 1700 1µ - 3
S145C Integr. Sphere (2”) InGaAs
∅ 12
800 - 1700 10µ - 20
S150C Fiber Head Si 3.6 x 3.6 350 - 1100 100p - 5m
S151C Fiber Head Si 3.6 x 3.6 400 - 1100 1n - 20m
S154C Fiber Head InGaAs
∅ 2.0
700 - 1700 100p - 5m
S155C Fiber Head InGaAs
∅ 2.0
700 - 1700 1n – 20m
Thermal Power Sensors:
Order Code Type Aperture
mm
Wavelength
nm
Power
W
S302C Thermally Stabilized
Thermal Absorber
∅ 12
190 - 25000 100µ - 2
S310C Thermal Surface Absorber
∅ 20
190 - 25000 10m - 10
S314C Thermal Surface Absorber
∅ 25
190 - 10600 10m - 60
S322C Thermal Surface Absorber
∅ 25
190 - 10600 100m - 250
S350C Thermal Surface Absorber
Excimer Coating
∅ 40
190 - 1100
and 10600
10m - 60
S370C Thermal Volume Absorber
for high peak power lasers
∅ 25
400 - 5200 10m - 15
7

THORLABS PM100D Specifications

General

Data Logging	Yes
Storage Temperature Range	-20 °C to 70 °C
Power Accuracy	±0.5% of reading
Interface	USB
Power Supply	USB or AC Adapter
Display Update Rate	10 Hz
Detector Type	Photodiode or Thermopile (Sensor Dependent)
