General Data
Detector Compatibility
Photodiode Sensors S100C Series
Thermal Sensors S300C Series
Pyroelectric Sensors ES100C/ES200C Series
Photodiodes (max. 5.5mA)
Thermopiles (max. 1.1V)
Pyros (max. 110V)
Display Type
4“ Graphical LCD 320 x 240 pixels
Viewing Area
81,4 x 61,0 mm
Display Update Rate (max)
20 Hz
Display Format
Numerical, Bargraph, Trendgraph, Histogram, Statistics,
Simulated Analog Needle
Backlight Display and Keypad
LED
Dimensions (H x W x D) Overall
183 x 109 x 40 mm³ with rubber boot
Options
Kickstand; 1/4“-20 Post thread
Weight
< 0.5 kg
Operating Temperature
0°C - +40°C
Storage Temperature
-40°C - +70°C
Relative Humidity
Max. 80% up to 31 °C, decreasing to 50% at 40 °C
Operation Altitude
< 3000 m
Current Input (Photodiode Sensors)
Connector
DB9F, left side
Units
W, dBm, W/cm², A
Measurement Ranges
6 decades; 50 nA … 5 mA
Ranges selectable in W or A, sensor depending
Display Resolution
1 pA / responsivity value (A/W)
AD Converter
16 bit
Accuracy
+/- 0.2% f.s. (5 µA – 5 mA)
+/- 0.5% f.s. (50nA)
Bandwidth
DC – 100 kHz, depending on sensor and settings
Photodiode Polarity
Cathode ground
Max. Photodiode Impedance
10 nF
Input Resistance
0 Ω (virtual ground)
Wavelength Correction
nm (A/W)
Beam Diameter Setting
1/e²
Voltage Input (Thermopile Sensors)
Connector
DB9F, left side
Units
W, dBm, W/cm², V
Measurement Ranges
4 decades; 1 mV … 1V
Ranges selectable in W or V, sensor depending
Display Resolution
1 µV / responsivity value (V/W)
AD Converter
16 bit
Accuracy
+/- 0.5% f.s.
Bandwidth
DC - 10Hz, depending on sensor and settings
Input Impedance
1 MΩ
Time Constant Correction Range
1 s – 30 s
Wavelength Correction
Sensor depending; nm, (V/W)
Beam Diameter Setting
1/e²
66

THORLABS PM100D Specifications

General

Data Logging	Yes
Storage Temperature Range	-20 °C to 70 °C
Power Accuracy	±0.5% of reading
Interface	USB
Power Supply	USB or AC Adapter
Display Update Rate	10 Hz
Detector Type	Photodiode or Thermopile (Sensor Dependent)
