THORLABS PM100D User Manual

8.3 Technical data
Voltage Input (Pyro Sensors)
Connector
DB9F, left side
Units
J, J/cm², W, W/cm², V
Measurement Ranges
4 decades; 100mV … 100V
Ranges selectable in J or V, sensor depending
Display Resolution
100µV / responsitivity value (V/J)
AD Converter
16 bit
Accuracy
+/- 0.5% f.s.
Trigger Threshold
0.1% - 99.9% f.s.
max. Repetition Rate
3 kHz
Input Impedance
1 MΩ
Wavelength Correction
Sensor depending; nm, (V/J)
Beam Diameter Setting
1/e²
Analog Outputs
Connector
SMA, left side
Signal
amplified input signal
Voltage Range
0 .. 2 V
Bandwidth
up to 100 kHz, depending on sensor and settings
Sensor Temperature Control
Supported temperature sensor
Thermistor
Temperature measurement range
-10 °C .. +80 °C
Sound
Type
Speaker 300 Hz – 5 kHz
Function
Laser tuning support, console function support
Memory
Type
SD Card
Size
2 GB
Interface
Type
USB2.0
Connector
Mini USB, left side
Power Management
Battery
LiPo 3.7 V 1300 mAh
External power supply DC Input
5 VDC
AC adapter input
100 V – 240 V; 50 Hz – 60 Hz
Accessories
AC Adapter
X
Hardcase
X
Instrument Drivers on USB Stick
X
Application Software on USB Stick
X
User Manual
X
SD Memory Card 1GB
X
67

THORLABS PM100D Specifications

General

Data Logging	Yes
Storage Temperature Range	-20 °C to 70 °C
Power Accuracy	±0.5% of reading
Interface	USB
Power Supply	USB or AC Adapter
Display Update Rate	10 Hz
Detector Type	Photodiode or Thermopile (Sensor Dependent)
