THORLABS PM100D User Manual

8.3 Technical data
Current Input Phtodiode Sensors
Current Range Display
Resolution
Measurement
Accuracy
Analog Output
Gain
Analog Output
Bandwidth
1 µA +/- 0.2% f.s. 4 x 10
2
V/A 100 kHz / 25 Hz 5 mA
100 nA +/- 0.2% f.s. 4 x 10
3
V/A 100 kHz / 25 Hz 500 µA
10 nA +/- 0.2% f.s. 4 x 10
4
V/A 100 kHz / 25 Hz 50 µA
1 nA +/- 0.2% f.s. 4 x 10
5
V/A 100 kHz / 25 Hz 5 µA
100 pA +/- 0.2% f.s. 4 x 10
6
V/A 10 kHz / 25 Hz 500 nA
10 pA +/- 0.5% f.s. 4 x 10
7
V/A 1 kHz / 25 Hz 50 nA
Voltage Input Thermal Sensors
Voltage Range Display
Resolution
Measurement
Accuracy
Analog Output
Gain
Analog Output
Bandwidth
100 µV +/- 0.5% f.s. 2 x 10
0
10 Hz 1 V
10 µV +/- 0.5% f.s. 2 x 10
1
10 Hz 100 mV
1 µV +/- 0.5% f.s. 2 x 10
2
7 Hz 10 mV
0.1 µV +/- 1.0% f.s. 2 x 10
3
0.7 Hz 1 mV
Voltage Input Pyroelectrical Sensors
Voltage Range Display
Resolution
Measurement
Accuracy
Analog Output
Gain
Analog Output
Bandwidth
100 mV +/- 0.5% f.s. 2 x 10
-2
50 kHz 100 V
10 mV +/- 0.5% f.s. 2 x 10
-1
50 kHz 10 V
1 mVV +/- 0.5% f.s. 2 x 10
0
50 kHz 1 V
100µV +/- 0.5% f.s. 2 x 10
1
50 kHz 0.1V
68

THORLABS PM100D Specifications

General

Data Logging	Yes
Storage Temperature Range	-20 °C to 70 °C
Power Accuracy	±0.5% of reading
Interface	USB
Power Supply	USB or AC Adapter
Display Update Rate	10 Hz
Detector Type	Photodiode or Thermopile (Sensor Dependent)
