5
Pull here to lift the support
Removable protective
Rubber boot
Figure 4 Rear View
Status Line with
Annunciators
Main Display
Configurable
Sub Display
Configurable
Sub Display
Bar Graph
Menu Soft
Buttons
Tool Tip Text
Header Line with Sensor Information, Date/Time and Battery state
Figure 5 Numeric Display Setup
