7
Button Appearance: Focus on Button Text Negative . Edit Mode Blinking frame.
All sub menus can be left by navigating to the EXIT button at the downright
soft button location or to any empty … e … button, and pressing the OK key.
System Settings
The following sub menus will appear:
- Measurement Settings
Remote state PM100D can be switched back to local mode
Line filter Sets the unit to the local line frequency 50Hz/60Hz
to avoid aliasing effects
Default sensor Sets the PM100D in a mode to measure photo
current, thermal voltage or peak voltage from a pyro-
electric detector.
See user manual.
- Console Settings
Language User interface language setting
Backlight Switches the LCD and key backlight on and off
(Same function as the key)
Brightness Sets the brightness of the LCD and key backlight.
The setting range is 0 – 100% in 1% increments
LCD Contrast Adjusts the LCD contrast.
The setting range is 0 – 100% in 1% increments
Sound Switches on and off the key and warning sounds
Shutdown The unit automatically powers off in battery
operation after a certain time without user action.
This feature can be set to 10 minutes, 1 hour or
switched off; and is not active when an external power
supply (AC adapter or USB) is connected.
Firmware Upload Needs to be ‘enabled’ before uploading a new
firmware version. The function will automatically reset
to ‘disabled’ when powering down.
- Date and Time Enters a submenu to set date and time. It is
possible to chose various date and time formats.
- Console Info Shows the console related information.
- Sensor Info Shows the related information of the currently
connected power or energy sensor.
