 6.4.6 Control Parameter Mode
■ Minimum/Maximum Limit of SV Limiter
Characte
r
Name Description Initial Value
1
SET3
CNT
Setting Mode Selection
Screen
Control Parameter Mode
Settings about Control
2
SLH
SV limiter upper limit Setting Range: Minimum setting range-Maximum setting range
Provided that the difference between SLH and SLL
must be more than 5°C(or °F).
Setting Unit: °C or °F
1200
3
SLL
SV limiter lower limit Setting Range: Minimum setting range-Maximum setting range
Provided that the difference between SLH and SLL
must be more than 5°C(or °F).
Setting Unit: °C or °F
0
・ Setting Range of the Maximum Limit of SV Limiter
When inputting thermocouple/resistance temperature detector: (SLL+5) up to maximum limit of setting range [°C]
(setting of the position of decimal point is 0)
: (SLL+5.0) up to maximum limit of setting range [°C]
(setting of the position of decimal point is 0.0)
・ Setting Range of the Minimum Limit of SV Limiter
When inputting thermocouple/resistance temperature detector: Minimum limit of setting range up to (SLL-5) [°C]
(setting of the position of decimal point is 0)
: Minimum limit of setting range up to (SLL-5.0) [°C]
(setting of the position of decimal point is 0.0)
■ Control mode setting
Character Name Description Initial Value
1
SET3
CNT
Setting Mode Selection
Screen
Control Parameter Mode
Settings about Control
4
MD
Control mode setting
RUN

Execute the Control
RDY

Stop the Control (Minimum Output of MV
Limiter)
MAN

Manual Control
RUN
 Execute the Control (RUN): Performs an ordinary control.
 Stop the Control (RDY): Outputs the minimum limit of the manipulated variable limiter of Output 1/2.
 Manual Control (MAN): Outputs the manipulated variable that is being set at Manipulated Variable of Output 1/2.
