TOHO TTM-i4N - Output Parameter Mode

56
6.4.7 Event □ Output Parameter Mode
■Event 1 Function Setting 1/Event 2 Function Setting 1/Event 1 Maximum and Minimum Limits Setting/Event 2 Maximum and
Minimum Limits Setting/Event 1 Sensitivity Setting/Event 2 Sensitivity Setting/Event 1 Delay Time Setting/Event 2 Delay Time
Setting
Character Name Description Initial Value
1
SET4
AL1

SET5
AL2
Setting Mode Selection
Screen
Event 1 Output
Parameter Mode
Event 2 Output
Parameter Mode
※ Set5 will not be displayed
unless the control type is set
Settings about Event 1 Output Function
Settings about Event 2 Output Function
2
A1F1
A2F1
Event 1 Function Setting
1
Event 2 Function Setting
1
Event Function
**0
No Function
**1
Maximum and Minimum Deviation Event
**2
Maximum Deviation Event
**3
Minimum Deviation Event
**4
Deviation Range Event
**5
Maximum and Minimum Absolute Value Event
**6
Maximum Absolute Value Event
**7
Minimum Absolute Value Event
**8
Absolute Value Range Event
Additional Function
*0*
None
*1*
Keep
*2*
Standby
*3*
Delay
*4*
Keep+Standby
*5*
Keep+Delay
*6*
Standby+Delay
*7*
Keep+Standby+Delay
Control Mode Interlock Function
0**
All modes
1**
RUN/MAN mode only
2**
RUN mode only
000
3
A1H
A2H
EV1 alarm upper limit
setting
EV2 alarm upper limit
setting
Setting Range: -1999–3276 or -199.9–999.9
□□□□□※In case of R/S/B thermocouple, -1999-3276
Setting Unit: °C or °F
0
4
A1L
A2L
EV1 alarm lower limit
setting
EV2 alarm lower limit
setting
Setting Range: -1999–3276 or -199.9–999.9
□□□□□※In case of R/S/B thermocouple, -1999-3276
Setting Unit: °C or °F
0
5
A1C
A2C
EV1 alarm sensitivity
setting
EV2 alarm sensitivity
setting
Setting Range: 0–999 or 0.0–999.9
Setting Unit: °C or °F
0
6
A1T
A2T
EV1 alarm delay timer
setting
EV2 alarm delay timer
setting
Setting Range: 0–9999
Setting Unit: Second
0
