TOHO TTM-i4N - Setting of the Unit of Timer; Setting of Start SV Permission Range

65
■ Setting of the Unit of Timer
Character Name Description Initial Value
1
SET6
TIME
Setting Mode Selection
Screen
Timer Parameter Mode
Settings about Timer
4
H/M
Setting of the Unit of
Timer
1

Hr. & Min.
2

Min. & Sec.
1
Sets the unit to be used for the timer function.
■Setting of Start SV Permission Range
Character Name Description Initial Value
1
SET6
TIME
Setting Mode Selection
Screen
Timer Parameter Mode
Settings about Timer
5
TSV
Setting of SV Start
Permission Range
Setting Range: 0–999 or 0.0–999.9
Setting Unit: °C or °F
0
When SV Start is set, it designates the range of temperature (°C) to start the timer.
As shown in the figure below, the permissible range will be designated by the range of tSV with SV as its center.
 SV        tSV
If tSV is set to 1.0°C, the timer will be activated when the value enters within the range of SV±0.5°C.
