TOHO TTM-i4N - Setting of the Sensitivity of Output 2; OFF Point Position Setting for OUT2

46
■ Setting of the Sensitivity of Output 2
Character Name Description Initial Value
1
SET3
CNT
Setting Mode Selection
Screen
Control Parameter Mode
Settings about Control
31
C2
Setting of the Sensitivity
of Output 2
Setting Range: 0–999 or 0.0–999.9
Setting Unit: °C or °F
1
Sets the sensitivity of output 2.
Sets the sensitivity (hysteresis) of ON/OFF action. In case of the cooling control, the sensitivity will be placed on top of SV.
■ OFF point position setting for OUT2
Character Name Description Initial Value
1
SET3
CNT
Setting Mode Selection
Screen
Control Parameter Mode
Settings about Control
32
CP2
OFF point position
setting for OUT2
Setting Range: -199–999 or -199.9–999.9
Setting Unit: °C or °F
0
Moves the OFF point of the sensitivity of output 2. The entire range of sensitivity will be moved.
Shifts the OFF point of Output 2 sensitivity. The entire range of sensitivity will be shifted.
