TOHO TTM-i4N - Specifications; General Specifications

72
9. Specifications
9.1 General Specifications
Storage Element EEPROM
Insulation See figure below
Power Supply Voltage AC100-240V 50/60Hz
Consumption Current 5VA or less
Warm-Up Time 30 minutes
Insulation Resistance Each Input and Output Terminal - Case DC500V 20MΩ
Power Source Terminal - Case DC500V 20MΩ
Voltage Endurance Each Input and Output Terminal - Case AC1000V 1 Minute
Power Source Terminal - Case AC1500V 1 Minute
Standard
Environment
Range of
Temperature
and Humidity
23°C±10°C/45%–75%RH
Operating
Environment
Range of
Temperature
and Humidity
0°C–50°C/20%–90%RH (without condensation)
Transportation
Environment
Range of
Temperature
and Humidity
-25°C–70°C(without freezing and condensation/5%–95%RH (without condensation)
Mechanism Specifications Weight 100g or less
Insulation Diagram
 Power Supply Input
Temperature
Input
CPU Circuit
Output 1
Event 1
Output 2/Event 2
        : Insulation    : Non-insulation
