TOHO TTM-i4N - Page 40

40
Sets the position of OFF point (offset for SV) for the ON/OFF operation of direct action.
Low HighSV
PV
OFF
ON
C1
OFF point CP1 0
C1 Sensitivity setting
Low HighSV
PV
OFF
ON
C1
OFF point CP1 negAtive vAlue
C1 Sensitivity setting
CP1 OFF-point position
D point SV CP1
CP1
D
point
Low HighSV
PV
OFF
ON
CP1
OFF point CP1 negAtive vAlue
C1 Sensitivity setting
CP1 OFF-point position
C point SV CP1
C1
C point
