55
SETTING FUNCTIONS ON SETUP SCREEN
DATA COMMUNICATION (COMM)
Comm contains settings related to data output with the external device.
LAN CONNECTION (LAN)
LAN contains settings related to data output via LAN.
OPERATOR SETTINGS
OPERATOR contains settings related to Operator ID.
SPECIAL
SPECIAL is a mode for service engineers only; it can not be accessed.
Descriptions Options Details Initial value
Communication Format
MODE1 Average value output format
MODE1
MODE2 Latest value output format
STD1 TOPCON STD1 format
STD2 TOPCON STD2 format
STD5 TOPCON STD5 format
Use of Output port
OFF Output port is disabled.
OFF
ON Output port is enabled.
Baudrate setting
2400bps Baudrate value: 2400bps
9600bps
9600bps Baudrate value: 9600bps
Descriptions Options Details Initial value
LAN connection
OFF LAN connection is off.
OFF
ON LAN connection is on.
Shared Folder Setting
Shared folder: string up to
32+1 characters including
terminated null char.
User name: string up to
32+1 characters including
terminated null char.
Pass word: string up to
16+1 characters including
terminated null char.
Set by keyboard display
Path and permission to the shared folder is set. NULL
IP Address Setting
FIX Assign IP address manually.
FIX
AUTO Assign IP address automatically.
IP Address
0. 0. 0. 0
Set by ten-key display
IP address of PC to output data. 0.0.0.0
Subnet Mask
0. 0. 0. 0
Set by ten-key display
Subnet mask address of CT-1P/CT-1. 0.0.0.0
Default Gateway
0. 0. 0. 0
Set by ten-key display
Default gateway address of CT-1P/CT-1. 0.0.0.0
Primary DNS Server
0. 0. 0. 0
Set by ten-key display
Primary DNS Server number. 0.0.0.0
Secondary DNS Server
0. 0. 0. 0
Set by ten-key display
Secondary DNS Server number. 0.0.0.0
Descriptions Options Details Initial value
Use of Operator ID
OFF
Operator ID will not be displayed on the control panel
and printer output.
OFF
ON
Operator ID will be displayed on the control panel
and printer output.
Prefix of Ope. ID
ASCIIZ string up to
3+1 characters including
terminated null char.
The Prefix of Operator ID can be registered. NULL
Operator ID (Mandatory)
OFF Operator ID is not required.
OFF
ON Operator ID is required.
Fixed Ope. ID setting
OFF Operator ID is not fixed.
OFF
ON Operator ID is fixed.
Fixed Ope. ID entry
ASCIIZ string up to
13 characters including
terminated null char.
Input fixed operator ID. NULL
To Next Page
