Topcon CT-800 - Alignment and Measurement

31
BASIC OPERATIONS
BASIC OPERATIONS
MEASUREMENT
ALIGNMENT AND MEASUREMENT
Alignment operations are done with the control lever.
• The main body position can be fine-adjusted longitudinally and laterally by inclining the con-
trol level to each direction.
• The main body position can be fine-adjusted vertically by turning the control level right (up)
and left (down).
CAUTION
To avoid injury when operating the machine (for measurement and
control panel operation), be careful not to approach the finger to
space of movable part.
Operating the control lever
(for front, back, right and left
adjustment)
Operating the control lever
(for up/down adjustment)
