RELATION BETWEEN THE SETTING OF THE ILLUMINATION/FLASH LEVEL AND MAXIMUM RADIANCE
RELATION BETWEEN THE SETTING OF THE ILLUMI-
NATION/FLASH LEVEL AND MAXIMUM RADIANCE
When the maximum radiance is "1", the ratio of radiance is shown below in the setting of the illumination/
flash level.
Illumination level Flash level (in OCT+Color photography and Color photog-
raphy)
*In the case of DRI OCT-1 Model Triton
Display
level
Ratio of
radiance
Display level:
Normal
(at shipment)
Display level:
Low invasion
(at shipment)
Setting of
the flash
level (W•s)
Ratio of
radiance
1 0.417 16 1.00
2 0.500 14 0.87
3 0.646 11 0.73
4 0.875 9.6 0.61
5 1.000 +4 8.1 0.52
+3 6.8 0.43
+2 5.7 0.36
+1 4.8 0.31
0 +4 4.0 0.25
-1 +3 3.4 0.22
-2 +2 2.9 0.18
-3 +1 2.4 0.15
-4 0 2.0 0.13
-1 1.7 0.11
-2 1.4 0.09
-3 1.2 0.08
-4 1.0 0.06
Flash level (in OCT+Color photography and Color photog-
raphy)
*In the case of DRI OCT-1 Model Triton plus
Display level:
Normal
(at shipment)
Display level:
Low invasion
(at shipment)
Setting of
the flash
level (W•s)
Ratio of
radiance
89 1.00
75 0.84
63 0.71
53 0.59
+4 45 0.50
+3 38 0.42
+2 32 0.35
+1 27 0.30
0+4220.25
-1 +3 19 0.21
-2 +2 16 0.18
-3 +1 13 0.15
-4 0 11 0.12
-1 9.4 0.11
-2 7.9 0.09
-3 6.6 0.07
-4 5.6 0.06
