Topcon DRI OCT-1 Triton User Manual

83
DETAILS OF THE SETTING MENU
Fundus
(OCT)
Blink detection Level OFF
LOW
NORMAL
Timer Stop Message OFF
ON
OCT+Color Mode
• Changes the color fundus image quality
(Normal/Low).
Normal
Low Invasive
Flash Level
(Default Model Triton:3.9Ws Model Triton plus:22Ws)
1.0 – 16Ws (Model Triton)
5.6 – 89Ws (Model Tri-
ton plus)
*1
Gain
(Default Model Triton:4.0Ws Model Triton plus:0Ws)
0 – 24db *1
OCT+Auto Fluo Mode
Flash Level (Default 212Ws) 53.0 – 300.0Ws 212
Gain (Default 12db)
0 – 24db 12
Color
Fundus
Color Mode Normal
Low Invasive
Flash Level
(Default Model Triton:4.0Ws Model Triton plus:22Ws)
4.0Ws (Model Triton)
22Ws (Model Triton plus)
*1
Gain (Default 0db)
0 – 24db *1
Flash Level Adjustment (Peripheral) 0 – +4 +1
Flash Level Adjustment (30°Mask) -4 – +4 -1
Flash Level Adjustment (Stereo) -4 – +4 0
Peripheral Photo Pattern
4 X
4 +
5 X
5 +
8
9
Peripheral Photo Fixation Move Auto
Manual
FA/Auto
Fluo
Fundus
FA Mode
Flash Level (Default 32Ws) 7.9 – 63Ws 32
Gain (Default 12db)
0 – 24db 12
Flash Level Adjustment (Peripheral) 0 – +4 +1
Flash Level Adjustment (Stereo) -4 – +4 0
Auto Fluo Mode
Flash Level (Default 212Ws) 53.0 – 300.0Ws 212
Gain (Default 24db)
0 – 24db 24
Flash Level Adjustment (Peripheral) 0 – +4 +1
Flash Level Adjustment (Stereo) -4 – +4 0
Utility button Item button Item selector button At
shipment
