86
DETAILS OF THE SETTING MENU
*1: In the instrument without the fundus photography function, this is not displayed.
*2: When "Split" is selected for "OCT Capture Focus Type", you can select "Split", "Split+OCT" and
"OCT".
When "OCT" is selected for "OCT Capture Focus Type", you can select "OCT" only.
When "Split+OCT" is selected for "OCT Capture Focus Type", you can select "Split+OCT" and "OCT".
Small Pupil *1
• This function is usable only when the color fun-
dus capture icon is selected.
• When the pupil diameter of the patient is small
(pupil diameter is approx. φ4.0mm or less), the
small pupil diaphragm is automatically set and
the instrument takes a color picture of the fun-
dus. After taking a picture, the small pupil dia-
phragm is automatically removed. When you
set the small pupil diaphragm selector button to
"ON" on the control panel, the above automatic
setting is not done.
ON/OFF ON
OFF
Magnification Mode 45° Mask
30° Mask
Auto Optimize ON/OFF ON
OFF
Auto Z
•Detects the retina posi-
tion automatically, and
always displays the fun-
dus tomogram clearly
during observation.
ON
OFF
Z-lock After AutoZ
•After "Auto Z", the photo-
graphed fundus image is
automatically fixed.
ON
OFF
Auto Pola
•Adjusts the output sensi-
tivity of the fundus tomo-
gram to the optimum
automatically.
ON
OFF
Auto Adjust Z-lock position ON
OFF
Auto Shoot ON/OFF ON
OFF
Auto Tracking ON/OFF ON
OFF
Focusing Knob Focus Split
OCT
Split+OCT
Utility button Item button Item selector
button
At
shipment
To Next Page
