Topcon GPT-3000W Series User Manual

6-9
6 SPECIAL MODE (Menu Mode)
2) Z Coordinate Calculation from Known Point Measuring Data
[Example setting] Using coordinate data file
Operating procedure Operation Display
1
After pressing [MENU] key, press [F4](P
↓
) key to
get the menu on page 2.
[MENU]
[F4]
2
Press the [F1] key.
[F1]
3
Press the [F3](Z COORD.) key.
[F3]
4
Press the [F1](USE FILE) key.
5
Press the [F1](INPUT) key and enter the File
Name.
[F1]
[F1]
Enter FN
[F4]
6
Press the [F2] key.
[F2]
7
Press the [F1](INPUT) key and enter the Point
Number in coordinate data file.
[F1]
Enter PT#
[F4]
8
Press the [F3](YES) key and enter the Point
Number in coordinate data file.
[F3]
9
Press the [F1](INPUT) key and enter the height.
[F1]
Enter R. HT
[F4]
10
Collimate a prism on the point and press the
[F1](MEAS) key.
Measuring starts. *1)
Collimate P
[F1]
MENU 2/3
F1:PROGRAMS
F2:GRID FACTOR
F3:ILLUMINATION P
↓
PROGRAMS 1/2
F1:REM
F2:MLM
F3:Z COORD. P
↓
Z COORD.SETTING
F1:USE FILE
F2:DON’T USE
SELECT A FILE
FN:_________
INPUT LIST ––– ENTER
Z COORD.SETTING
F1:OCC.PT INPUT
F2:REF.MEAS
NOO1#
PT#:_________
INPUT LIST NEZ ENTER
N: 4.356 m
E: 16.283 m
Z: 1.553 m
>OK ? [YES][NO]
REFLECTOR HEIGHT
INPUT
R.HT: 0.000 m
INPUT ––– ––– ENTER
REFLECTOR HEIGHT
INPUT
R.HT: 0.000 m
MEAS ––– NP/P –––
HR: 120°30'40"
HD*[n] << m
VD: m
>Measuring...
