Receiver Specifications
P/N 7010-0816
A-7
GPS Board Details
Table A-2 lists the GPS board’s general specifications.
Table A-2. GPS Board Specifications
Receiver Type (set by activating the proper OAF)
Euro-112T
(HGGDT)
G: GPS L1
GD: GPS L1/L2
GG: GPS/GLONASS L1
GGD: GPS/GLONASS L1/L2
Tracking Specifications
Standard Channels 40 channels (G, GG, GD, GGD)
L1 GPS, L1/L2 GPS, L1 GLONASS, L1 GPS + L1
GLONASS, WAAS/EGNOS, PCode and Carrier
Optional Cinderella days (see page A-8 for details)
Tracked Signals GPS/GLONASS, L1/L2 C/A and P-Code and Carrier,
WAAS/EGNOS
Tracking Functions
Multi-path
reduction
Code and Carrier
PLL/DLL setting Bandwidth, order, adjustable
Co-op tracking loop
setting
On/Off, S
\tatic Mode, Bandwidth of individual PLL, Bandwidth of
common PLL
Smoothing interval Code and Carrier
WAAS/EGNOS WAAS optional
EGNOS optional
Data Features
Formats TPS, NMEA, RTCM, BINEX
