Topcon HiPer Ga User Manual

Receiver and File Maintenance
HiPer Ga/Gb Operator’s Manual
5-4
...Using Topcon Link
To download files using Topcon Link:
1. Connect your receiver and computer. See “Connecting the
Receiver and a Computer” on page 2-14 for this procedure.
2. To start Topcon Link, click Import from Device on the Toolbar.
3. From the left panel of the Import from Device dialog box,
double-click Topcon Receivers (Figure 5-5).
Figure 5-5. Import From Device Window
The program automatically searches for Topcon receivers
connected to the computer ports (COM and USB). When finished
all receivers connected to the computer ports (Figure 5-6) display.
Figure 5-6. Search for Topcon Receivers
4. To view information about the receiver, right-click the receiver
and select the Properties option (Figure 5-7 on page 5-5).

Topcon HiPer Ga Specifications

General

Brand	Topcon
Model	HiPer Ga
Category	Receiver
Language	English
