Topcon ISOCAN - Parts List

ISOCAN / ISOBUS ARTEMIS - SEED DRILL CONTROLLER
9
1.7 Parts List
Item #
Part No.
Description
Qty
P/ART3/ISOCAN
P/ART3/ISOBUS
P/ART3/ISOBUSNM
P/ART3/2ND
P/ART3/2NDNM
Tractor-based components (Figure 6)
10
S/HU/410-3-002
Isocan Head Unit
1
11
S/CB/411-1-026
Isocan Head Unit Cable
1
12
K/ISOCAN/MTG/KT
Isocan Mounting kit
1
13
S/CB/500-1-074
Power Cable - Tractor
1
1
1
Implement High-current Power Supply components (Figure 7)
20
K/ART2/PWR
Power Cable kit comprising :-
1
1
1
21
S/FR/500-6-064
M5 x 25 Hex. Set Screw
3
3
3
22
S/FSNR/940204
M5 Flat Washer
6
6
6
23
S/FR/500-6-051
M5 Nut
3
3
3
24
S/CB/268-6-021
Power Cable (5-metre) - Implement
1
1
1
25
S/W684-015
1-metre 14G Wire – Black
1
1
1
1
1
26
S/W684-016
1-metre 14G Wire – Red
1
1
1
1
1
27
S/H663-025
Fuse – 60 Amp
1
1
1
28
S/H661-012
Fuse Holder
1
1
1
29
S/T610-111
Wire Terminal - D25-6
2
2
2
30
S/T609-071
Wire Terminal – Yellow Ring
8
8
8
4
4
Implement-based components (Figure 8)
40
S/CB/500-1-156
ISOBUS Cable
1
1
41
S/CB/410-3-020
ISOBUS Extension Lead c/w CAN
1
1
1
42
S/AC/410-3-012
Type E ECU
1
1
1
43
S/SR/385-2-006
Satspeed 2 GPS Interface
1
1
1
44
S/TC/1015540-01
Expansion Harness (2 / 3 / 4-Motor)
1
1
1
1
1
45
S/AC/322-9-001
CAN Module – MCM
1
1
1
1
1
46
S/AC/268-6-043
Motor Assembly
1
1
1
47
S/AC/500-4-083
Motor Shaft
1
1
1
48
S/SR/201-2-006
Capacitance Sensor - Hopper Level
1
1
1
1
1
49
S/SR/500-2-107
Magnetic Sensor (Seed Shaft Confirmation / Fan Speed)
2
2
2
1
1
50
S/SW/500-7-019
Priming Switch
1
1
1
1
1
51
S/MG/185/1/013
Magnet - Fan Speed
1
1
1
52
S/MG/289-1-010
Magnet - Shaft Speed Confirmation
1
1
1
1
1
53
S/FR/500-6-051
M5 Nyloc Nut
15
15
15
8
8
54
S/FR/500-6-064
M5 Bolt
10
10
10
5
5
55
S/SW/500-7-018
Finger Switch
1
1
1
56
S/FSNR/940204
Washer
15
15
15
8
8
57
S/CB/322-5-013
MCM Earthing Strap
2
2
2
1
1
