5.1.1 Setting the MCM ID
It is necessary to set the identity of each MCM to the ECU as either ‘MCM-1’, ‘MCM-2’, ‘MCM-3’ or ‘MCM-4’. The wires
with ring terminals ‘I’, ‘J’ and ‘K’ must be connected to the MCM 0V stud in one of the following combinations.
Wire / ring terminal(s) to MCM 0V Stud
MCM ID
Blue only
1
Blue + Pink/Black
2
Blue + Purple/Red
3
Blue + Pink/Black + Purple/Red
4
For MCM-1, MCM-2 and MCM-3, it is recommended to apply heatshrink over the unused terminal(s), and cable-tie back
to the harness.
NOTE: The unused terminals must not be left loose or bare in such a way such that they could accidentally make contact with the
chassis.
5.1.2 Expansion Harness (S/TC/1015540-01) Wiring Table
NOTE: MCM’s have CAN Bus termination set by default via the Yellow/Black link wire (pin 1F to pin 2D on the Cinch connector).
Connections
MCM
Pin
Wire colour
Function
1A
Gray
+V
1B
Pink
Encoder - SIG
1C
Black
Shaft Conf. 1 - SIG
1D
Green
CAN LO
1E
Yellow
CAN HI
1F
Yellow/Black
CAN Termination Link
2A
White
-
2B
Orange
Shaft Conf. 2 - SIG
2C
Violet
Priming Switch - SIG
2D
Yellow/Black
CAN Termination Link
2E
Red
Module ON
2F
Pink/Black
MCM ID
3A
-
3B
White/Red
Hopper level 2 - SIG
3C
Red/Green
Hopper level 1 - SIG
3D
Purple/Red
MCM ID
3E
-
-
3F
Brown
+V
I
Ring
term.
Blue
0V / MCM ID
J
Pink/Black
MCM ID
K
Purple/Red
MCM ID
Connections
A
Pin
Wire colour
Function
1
Blue
0V
2
Pink
Encoder - SIG
3
Gray
+V
B
1
Brown
Power IN +V
2
White
-
3
Blue
Power IN 0V
4
Red
Module ON
5
Green
CAN LO
6
Yellow
CAN HI
C
1
Brown
Power OUT +V
2
White
-
3
Blue
Power OUT 0V
4
Red
Module ON
5
Green
CAN LO
6
Yellow
CAN HI
D
A
Brown
+V
B
Blue
0V
C
White/Red
Hopper level 2 - SIG
E
A
Brown
+V
B
Blue
0V
C
Red/Green
Hopper level 1 - SIG
F
A
Brown
+V
B
Blue
0V
C
Black
Shaft Conf. 1 - SIG
G
A
Brown
+V
B
Blue
0V
C
Orange
Shaft Conf. 2 - SIG
H
A
Brown
+V
B
Blue
0V
C
Violet
Priming Switch - SIG
