ISOCAN / ISOBUS ARTEMIS - SEED DRILL CONTROLLER
22
Status LEDs
There are two LED’s indicating the unit’s status as follows,
PWR (Green)
GPS (Red)
Unit Status
Off
Off
No power
On
Off
Power but no GPS signal (No forward speed reading)
On
Flash*
Power + Standalone GPS (should result in forward speed reading)
On
On
Power + Differential GPS (optimal performance – EGNOS support)
* Flashes @ VTG message frequency e.g. 4Hz
4.3.2 GPS / ISOBUS
If for whatever reason the Satspeed 2 is not utilised, and Forward speed signal is instead obtained from the ISOBUS,
then set “Speed Source” to “GPS/ISOBUS”.
NOTE: In addition to the setting in the Artemis app, you must also check that the UT is configured to enable the RS232 input from
the GPS receiver to be enabled on the ISOBUS so that the Artemis App can recognize it. This example shows the Topcon
X25 terminal. For other UT’s if necessary, please refer to the UT user manual.
