Groundsmaster 4000--DHydraulic System (Rev. B) Page 4 -- 100
Front Deck Lift Cylinder
1. Lift cylinder
2. Upper lift pin
3. Cotter pin
4. Pin assembly
5. Cap screw
6. Flat washer
7. Lock nut
8. Lift arm assembly (LH shown)
9. O--ring
10. Straight hydraulic fitting
11. O-- ring
12. 90
o
hydraulic fitting
Figure 77
8
5
4
1
3
2
7
6
10
11
9
12
11
9
6
1
FRONT
RIGHT
