Toro 30410 - Side Cutting Unit

Groundsmaster 4000−DCutting Units
Page 8 − 8
Side Cutting Unit
1. Side cutting deck (LH shown)
2. Deck mount (LH shown)
3. Flange head screw
4. Flat washer
5. Lock nut
6. Clevis pin
7. Hair pin
8. Jam nut
9. Rod end
10. Damper link tube
Figure 5
6
8
FRONT
RIGHT
10
9
7
1
8
9
2
3
4
5
