Toro 30410 - Service and Repairs; Air Filter System

Groundsmaster 4000−DPage 3 − 6Kubota Diesel Engine (Rev. B)
Service and Repairs
Air Filter System
Figure 3
1. Air cleaner hose
2. Hose clamp
3. Air cleaner assembly
4. Indicator
5. Air cleaner strap
6. Lock nut
7. Hose clamp
8. Air cleaner hose
9. Hose clamp
10. Cap screw
11. Flat washer
8
1
3
4
5
6
9
7
10
11
2
11
FRONT
RIGHT
EVACUATOR
DIRECTION
