Groundsmaster 4000--D/4010--DHydraulic System Page 4 -- 11 8
Steering Cylinder Service
1. Barrel
2. Rod
3. Piston
4. Head
5. Internal collar
6. Backup ring
7. O--ring
8. Dust seal
9. Rod seal
10. O--ring
11. Piston seal
12. Lock nut
Figure 85
40 ft--lb
(54 N--m)
1
6
7
3
9
10
4
11
2
8
5
12
1
6
7
3
9
8
10
4
11
2
5
12
