Toro 30410 - Exhaust System

Groundsmaster 4000−DPage 3 − 8Kubota Diesel Engine (Rev. B)
Exhaust System
Figure 5
1. Muffler
2. Muffler bracket
3. Exhaust pipe
4. Flange head screw
5. Exhaust gasket
6. Lock nut
7. Cap screw
8. Flat washer
9. Spacer
10. Rubber hanger
11. Flange nut
12. Flange head screw
13. Engine mount
14. Muffler clamp
11
2
1
14
3
12
4
11
7
8
6
10
8
7
6
9
13
16 to 22 ft−lb
(21 to 29 N−m)
16 to 22 ft−lb
(21 to 29 N−m)
16 to 22 ft−lb
(21 to 29 N−m)
5
FRONT
RIGHT
