Toro Groundsmaster 4500-D Series - Chapter 5:Hydraulicsystem; General Information; Check Hydraulic Fluid; Operators Manual

GeneralInformation
Operator’sManual
TheOperator’sManualprovidesinformationregardingtheoperation,general
maintenanceandmaintenanceintervalsforyourGroundsmastermachine.Refer
tothatpublicationforadditionalinformationwhenservicingthemachine.
CheckHydraulicFluid
g307854
Figure26
1.Hydraulicreservoir2.Reservoircap
TheGroundsmasterhydraulicsystemisdesignedtooperateonanti−wear
hydraulicuid.Thehydraulicreservoirlocatedbeneaththeoperatorseatholds
approximately28.4liters(7.5U.S.gallons)ofhydraulicuid.Checklevelof
hydraulicuiddaily.SeeOperator’sManualforuidlevelcheckingprocedure
andoilrecommendations.
TowingTractionUnit
g307867
Figure27
1.Bypassvalvelocation
Groundsmaster
®
4500-D/4700-D
Page5–3
HydraulicSystem:GeneralInformation
19245SLRevA
