RevisionHistory

RevisionDateDescription

A

04/2020

Initialissue.

RevisionHistoryPage2

Groundsmaster

®

4500-D/4700-D

19245SLRevA

Table of Contents

Table of Contents7
- Chapter 1 :Safety10
  - Safety Instructions10
  - Safety and Instructional Decals17
Table of Contents19
- Chapter 2 :Specificationsandmaintenance20
Table of Contents41
- Chapter 3 :Troubleshooting42
General Information/Service and Repairs73
- Chapter 4 :Yanmardieselengine74
  - General Information74
  - Service and Repairs81
Table of Contents103
- Chapter 5 :Hydraulicsystem105
Table of Contents283
- Default Chapter284
  - General Information284
- Chapter 6 :Electricalsystem301
Table of Contents359
- Chapter 7 :Axles,Planetariesandbrakes360
General Information/Service and Repairs405
- Chapter 8 :Chassis406
  - General Information406
    - Cutting Deck Identification406
    - Operator's Manual406
  - Service and Repairs407
- Chapter 9 :Cuttingdecks434
Table of Contents453
