1
InstallingtheSteering
Wheel
TCModelsOnly
Partsneededforthisprocedure:
1
Steeringwheel
1
Cover
1
Washer(5/8inch)
Procedure
1.Ifthecoverisinstalled,removeitfromthehub
ofthesteeringwheel(Figure3).
2.Removethenutfromthesteeringshaft(Figure
3).
3.Slidethesteeringwheelandwasherontothe
steeringshaft(Figure3).
4.Securethesteeringwheeltotheshaftwiththe
nutandtightenitto27to34N∙m(20to25ft-lb).
5.Installthecoveronthesteeringwheel(Figure3).
g024240
Figure3
1.Cover4.Steeringwheel
2.Nut
5.Steeringshaft
3.Washer(5/8inch)
2
ConnectingtheBattery
TCModelsOnly
NoPartsRequired
Procedure
WARNING
Incorrectlyroutingthebatterycablecould
damagethemachineandcables,causing
sparks.Sparkscancausethebatterygasses
toexplode,resultinginpersonalinjury.
•Alwaysdisconnectthenegativebattery
cable(black)beforedisconnectingthe
positivebatterycable(red).
•Alwaysconnectthepositivebatterycable
(red)rst.
1.Squeezethebatterycovertoreleasethetabs
fromthebatterybase(Figure4).
g010326
Figure4
1.Batterycover
2.Removethebatterycoverfromthebatterybase
(Figure4).
3.Connectthepositivebatterycable(red)tothe
positive(+)terminalofthebatteryandsecure
thecablewiththeboltsandnuts(Figure5).
12
