Lubrication
GreasingtheBearingsand
theBushings
ServiceInterval:Every100hours(lubricate
morefrequentlyinheavy-duty
applications).
GreaseType:No.2lithiumgrease
Important:Whengreasingthedriveshaft
universalshaftbearingcrosses,pumpgrease
untilitcomesoutofall4cupsateachcross.
1.Usearagtowipethegreasettingcleansothat
foreignmattercannotbeforcedintothebearing
orbushing.
2.Withagreasegun,applygreaseintothegrease
ttingsonthemachine.
3.Wipeanyexcessgreaseoffthemachine.
Thegreasettinglocationsandquantitiesareas
follows:
•Balljoints(4);refertoFigure36
•Pivotmounts(2);refertoFigure36
•Steeringcylinder(2);refertoFigure36
•Tierods(2);refertoFigure36
g010360
Figure36
•Springtower(2);refertoFigure37
g010571
Figure37
•Brake(1);refertoFigure38
•Throttle(1);refertoFigure38
g025519
Figure38
39
