ConnectingtheCVT-Intake
Duct
NoPartsRequired
Procedure
Important:Removetheplasticbagcoveringthe
endoftheCVTductbeforestartingtheengine.
TheCVTKit(PartNo.121-9853)andAdapterKit
(PartNo.127-8750)arerequiredforthisprocedure.
1.Loosenthehoseclampsecuringtheplasticbag
attheendoftheCVT-intakehoseandremove
thebag.
2.Raisethecargobedbyperformingthefollowing:
A.Engagetheparkingbrake.
B.Starttheengine.
C.Movethehydraulic-liftleverrearwardto
raisethecargobox.
D.Shutofftheengine.
E.Removethebedsupportfromthestorage
bracketsonthebackoftheROPSpanel
andinstallthesupportontothecylinderrod
ofthebed-liftcylinder;refertoUsingthe
BedSupport(page35).
3.AligntheCVT-intakehoseontotheintake-tube
connectoratthebacksideoftheROPSpanel
andtightenthehoseclamp(Figure7).
g026251
Figure7
1.CVT-intakehose
3.Intake-tubeconnector
2.Hoseclamp
4.Removethebedsupport,lowerthebed,shutoff
theengine,andremovethekey.
6
BurnishingtheBrakes
NoPartsRequired
Procedure
Toensureoptimumperformanceofthebrakesystem,
burnishthebrakesbeforeuse.
1.Bringthemachineuptofullspeed,applythe
brakestorapidlystopthemachinewithout
lockingupthetires.
2.Repeatthisprocedure10times,waiting1minute
betweenstops,toavoidoverheatingthebrakes.
Important:Thisprocedureismosteffective
ifthemachineisloadedwith454kg(1,000
lb).
