continuouscranking,wait60secondsbefore
engagingstartermotoragain.
DrivingtheMachine
1.Pressthebrakepedal.
2.Disengagetheparkingbrake.
3.Movethetransmissionlevertothedesiredgear.
4.Releasetheservicebrakeandgraduallypress
intheacceleratorpedal.
Important:Alwaysstopthemachinebefore
shiftingtoreverseaforwardgearortoa
forwardgearfromreverse.
Usethechartbelowtodeterminetheground
speedofeachgearwhenoperatingthe
machinewiththespeed-rangecontrolintheT
(TRANSPORT)position.
GearSpeed(km/h)Speed(mph)
R(REVERSE)
0to210to13
L(LOWFORWARD)
0to180to11
D(DRIVE)
0to320to20
Note:Avoididlingtheengineforlongperiods
oftime.
Note:LeavingthekeyswitchintheONposition
forlongperiodsoftimewithoutstartingthe
enginedischargesthebattery.
StoppingtheMachine
Tostopthemachine,removeyourfootfromthe
acceleratorpedal,thenpressthebrakepedal.
ShuttingOfftheEngine
1.Stopthemachine.
2.MovethetransmissionlevertotheP(PARK)
position.
3.Engagetheparkingbrake.
4.RotatethekeyswitchtotheOFFpositionand
removethekey.
UsingtheSpeed-Range
Control
Usetheleverofthespeed-rangecontroltolimitthe
maximumgroundspeedofthemachineforoperations
thatrequireaconstantspeedlikesprayingandtop
dressing.Thespeed-rangelever(Figure23)isused
toselect1ofthe4work-speedrangesthatareused
tolimitmaximumgroundspeedoratransport-speed
rangethatisusedwhenyoumovethemachine
betweenjobsites.
Note:Youmustreleasetheacceleratorpedalin
ordertoshiftbetweenspeedranges,butyoudonot
needtostopthemachineinordertoshift.
Movethespeed-rangeleverintothedetentfor
speedrangesA,B,C,andDwhenprecisecontrol
ofmaximum-groundspeedisdesired.
Movethespeed-rangelevertotheT(TRANSPORT)
positionbymovingthespeed-rangeleveroutof
thedetentforrangeA,B,C,orD,thenforwardto
theT(TRANSPORT)position.
Note:Usethespeed-rangecontroltolimitthe
maximumgroundspeedineachrangeby4to18
km/h(2.5to11mph)withthetransmissionleverin
theL(LOWFORWARD)positionor8to32km/h(5to
20mph)withthetransmissionleverintheintheD
(DRIVE)position.
g024320
Figure23
1.Speed-rangelever4.C(mid-highrange)
2.T(transportrange)5.B(mid-lowrange)
3.D(highrange)6.A(lowrange)
27
