g009824
Figure34
1.Rearjackingpoints
RemovingandInstalling
theHood
RemovingtheHood
1.Whilegraspingthehoodintheheadlight
openings,liftupthehoodtoreleasethelower
mountingtabsfromtheframeslots(Figure35).
g010314
Figure35
1.Hood
2.Pivotthebottomofthehoodupwarduntilyou
canpullthetopmountingtabsfromtheframe
slots(Figure35).
3.Pivotthetopofthehoodforwardandunplugthe
wireconnectorsfromtheheadlights(Figure35).
4.Removethehood.
InstallingtheHood
1.Connectthelights.
2.Insertthetopmountingtabsintotheframeslots
(Figure35).
3.Insertthelowermountingtabsintotheframe
slots(Figure35).
4.Ensurethatthehoodisfullyengagedinthetop,
sides,andbottomgrooves.
38
