RemovingtheFullBed
1.Starttheengine,engagethehydraulic-liftlever,
andlowerthebeduntilthecylindersareloose
intheslots.
2.Releasetheliftleverandshutofftheengine.
3.Removethelynchpinsfromtheouterendsof
thecylinderrodclevispins(Figure30).
g002368
Figure30
1.Cylinderrodend
4.Lynchpin
2.Bed-mountingplate
5.Rearslots(fullbed)
3.Clevispin6.Frontslots(2/3fullbed)
4.Removetheclevispinssecuringthecylinderrod
endstothebed-mountingplatesbypushingthe
pinstowardtheinside(Figure30).
5.Removethelynchpinsandclevispinssecuring
thepivotbracketstotheframechannels(Figure
30).
6.Liftthebedoffthemachine.
CAUTION
Thefullbedweighsapproximately148kg
(325lb),sodonottrytoinstallorremove
itbyyourself.
Useanoverheadhoistorgetthehelpof
2or3otherpeople.
7.Storethecylindersinthestorageclips.
8.Engagethehydrauliclift-lockleveronthe
machinetopreventaccidentalextensionofthe
liftcylinders.
InstallingtheFullBed
Note:Ifyouareinstallingthebedsidesontheat
bed,itiseasiertoinstallthembeforeinstallingthe
bedonthemachine.
Ensurethattherearpivotplatesareboltedtothebed
frame/channelsothatthelowerendanglestotherear
(Figure31).
g002369
Figure31
1.Left,rearcornerofbed4.Clevispin
2.Machineframechannel
5.Lynchpin
3.Pivotplate
CAUTION
Thefullbedweighsapproximately148kg
(325lb),sodonottrytoinstallorremoveit
byyourself.
Useanoverheadhoistorgetthehelpof2or3
otherpeople.
Ensurethatthespacerbracketsandwearblocks
(Figure32)areinstalledwiththecarriage-boltheads
positionedinsidethemachine.
