ElectricalSystem
Maintenance
ElectricalSystemSafety
Disconnectthebatterybeforerepairingthe
machine.Disconnectthenegativeterminalrst
andthepositivelast.Connectthepositiveterminal
rstandthenegativelast.
Chargethebatteryinanopen,well-ventilated
area,awayfromsparksandames.Unplugthe
chargerbeforeconnectingordisconnectingthe
battery.Wearprotectiveclothinganduseinsulated
tools.
ServicingtheFuses
Thefusesfortheelectricalsystemarelocatedunder
thecenterofthedashpanel(Figure49andFigure50).
g025637
Figure49
1.Fuses
decal127-8626a
Figure50
1.Powertakeoff(15A)5.Differentiallock(15A)
2.Enginestart(10A)6.Speedometer(10A)
3.Hazards(10A)
7.Headlightsandrearlights
(15A)
4.Engineignition(10A)8.Horn(30A)
45
