ProductOverview
Controls
Becomefamiliarwithallthecontrolsbeforeyoustart
theengineandoperatethemachine.
AcceleratorPedal
Usetheacceleratorpedal(Figure8)tovarytheground
speedofthemachinewhenthetransmissionisin
gear.Pressingdowntheacceleratorpedalincreases
theenginespeedandgroundspeed.Releasingthe
pedaldecreasestheenginespeedandgroundspeed.
g024307
Figure8
1.Brakepedal2.Acceleratorpedal
BrakePedal
Usethebrakepedaltostoporslowthemachine
(Figure8).
CAUTION
Operatingamachinewithwornorincorrectly
adjustedbrakescanmayresultinpersonal
injury.
Ifthebrakepedaltravelstowithin25mm(1
inch)ofthemachineoorboard,adjustor
repairthebrakes.
TransmissionLever
Usethetransmissionlever(Figure9)toshiftthe
transmissionbetweenP(PARK),R(REVERSE),N
(NEUTRAL),L(LOWFORWARD),andD(DRIVE)ground
operation.
Important:Donotshiftthetransmissiontothe
REVERSE,LOW,orDRIVEgearunlessthemachine
ismotionlessandtheengineisatlowidle;
otherwise,youcoulddamagethetransmission.
g028609
Figure9
1.Transmissionlever
4.N(neutral)
2.P(park)5.L(lowforward)
3.R(reverse)6.D(drive)
