Parking-BrakeLever
Wheneveryoushutofftheengine,engagethe
parkingbrake(Figure10)topreventthemachinefrom
accidentallymoving.Ifthemachineisparkedona
steepgrade,ensurethatyouengagetheparking
brake.
•Toengagetheparkingbrake,pullbackonthe
parking-brakelever.
•Todisengagetheparkingbrake,pushthe
parking-brakeleverforward.
Note:Disengagetheparkingbrakebefore
movingthemachine.
•Ifyouparkthemachineonasteepuphillor
downhillgrade,shiftthetransmissionintoP(PARK)
andengagetheparkingbrake.Placechocksat
thedownhillsideofthewheels.
g028610
Figure10
1.Parking-brakelever
Hydraulic-LiftLever
Thehydraulicliftraisesandlowersthebed.Move
thehydraulic-liftleverrearwardtoraisethebed,and
forwardtolowerit(Figure11).
Important:Whenloweringthebed,holdthelever
intheforwardpositionfor1to2secondsafterthe
bedcontactstheframetosecureitinthelowered
position.Donotholdthehydraulicliftintheraise
orlowerpositionformorethan5seconds,once
thecylindersreachtheendoftheirtravel.
g024361
Figure11
1.Lowerthebed4.Unlocked
2.Raisethebed
5.Hydraulic-liftlock
3.Locked
6.Hydraulic-liftlever
Hydraulic-LiftLock
Thehydraulic-liftlocksecurestheliftlever,sothatthe
hydrauliccylindersdonotoperatewhenthemachine
isnotequippedwithabed(Figure11).Italsolocksthe
liftleverintheONpositionwhenusingthehydraulics
forattachments.
Speed-RangeLever
Usethespeed-rangelever(Figure12)toselect1of
the4work-speedrangesforprecisecontrolofthe
maximumgroundspeedoratransportspeedrange
formovingthemachinebetweenjobsites.
g024320
Figure12
1.Speed-rangelever4.C(mid-highrange)
2.T(transportrange)5.B(mid-lowrange)
3.D(highrange)6.A(lowrange)
