2.Loosenthesetscrewsecuringtheknobtothe
parking-brakelever(Figure75).
g033259
Figure75
1.Knob3.Parking-brakelever
2.Setscrew
3.Rotatetheknob(Figure75)untilaforceof20
to22kg(45to50lb)isrequiredtoactuatethe
lever.
4.Tightenthesetscrewwhennished(Figure75).
Note:Ifyoucannolongermakeaparking-brake
adjustmentbyadjustingtheparking-brake
lever,loosenthehandletothemiddleofthe
adjustmentandadjustthecableattherear,then
repeatstep3.
5.Installtherubbergripontotheparking-brake
lever(Figure74).
AdjustingtheBrakePedal
ServiceInterval:Every200hours
1.Removethehood.
2.Removethecotterpinandclevispinsecuring
themastercylinderyoketothebrake-pedal
pivot(Figure76).
g025532
Figure76
1.Cotterpin
4.Mastercylinderyoke
2.Brake-pedalpivot5.Jamnut
3.Clevispin
3.Liftuponthebrakepedal(Figure77)untilit
contactstheframe.
g025531
Figure77
1.Brakepedal2.Acceleratorpedal
4.Loosenthejamnutssecuringtheyoketothe
mastercylindershaft(Figure76).
5.Adjusttheyokeuntilitsholesalignwiththehole
inthebrake-pedalpivot(Figure76).
6.Securetheyoketothepedalpivotwiththeclevis
pinandcotterpin(Figure76).
7.Tightenthejamnutsecuringtheyoketothe
mastercylindershaft(Figure76).
Note:Thebrakemastercylindermustrelieve
thepressurefromtheservicebrakewhenitis
properlyadjusted.
8.Installthehood.
57
