4 Replacement Procedures 4.8 Optical disk drive (DVD-super multi drive)
2. Close the display and turn over the computer.
3. Remove the following screw and pull out the optical disk drive.
• M2.5×6B FLAT HEAD screw ×1
M2.5x6B FLAT HEAD
Optical disk drive
Figure 4-15 Removing the optical disk drive (2)
4-26 [CONFIDENTIAL] QOSMIO G50 Maintenance Manual (960-683)
