Appendices Appendix B Board Layout
B-4 [CONFIDENTIAL] QOSMIO G50 Maintenance Manual (960-683)
Table B-2 System board (F
DUSY
*) connectors
and ICs (back)
Number Name
CN1400 Memory A connector
CN1410 Memory B connector
CN1900 1
st
HDD SATA I/F connector
CN1910 ODD SATA I/F connector
CN1930 eSATA/USB(Port6) I/F connector
CN2420 PCI TV tuner I/F connector
CN2440 BCAS I/F connector: Japanese model only
CN2520 EXPRESS CARD I/F connector
CN2710 RF I/F connector
CN2800 PCI-E Mini CARD I/F (slot4) connector
CN2801 POWER connector
CN4230 IEEE1394 I/F connector
CN4612 USB(PORT0) I/F connector
CN5320 RGB I/F connector
CN5350 HDMI I/F connector
CN5900 GFX I/F connector
CN8771 CPU FAN I/F connector
CN8781 VGA FAN I/F connector
CN8810 Battery connector
J4100 LAN I/F connector
J9600 IR BRUSTER1 I/F connector
J9601 IR BRUSTER2 I/F connector
IC1050 CPU
IC1200 North Bridge
IS2140 MEDIA BRIDGE I/F connector
