Toshiba QOSMIO G50 Maintenance Manual

Appendix C Pin Assignments Appendices
Qosmio G50 Maintenance Manual (960-683) [CONFIDENTIAL] C-5
Table C-2 Memory B connector (200-pin) (2/3)
Pin No. Signal Name Pin No. Signal Name
61 BDQ29-B1P 62 BDQ28-B1P
63 BDQ25-B1P 64 BDQ24-B1P
65 GND 66 GND
67 BDM3-B1P 68 BDQS3-B1N
69 NC 70 BDQS3-B1P
71 GND 72 GND
73 BDQ26-B1P 74 BDQ31-B1P
75 BDQ30-B1P 76 BDQ27-B1P
77 GND 78 GND
79 MCKE3-B1P 80 MCKE4-B1P
81 1R8-B1V 82 1R8-B1V
83 NC 84 NC
85 BBS2-B1P 86 BMA14-B1P
87 1R8-B1V 88 1R8-B1V
89 BMA12-B1P 90 BMA11-B1P
91 BMA09-B1P 92 BMA07-B1P
93 BMA08-B1P 94 BMA06-B1P
95 1R8-B1V 96 1R8-B1V
97 BMA05-B1P 98 BMA04-B1P
99 BMA03-B1P 100 BMA02-B1P
101 BMA01-B1P 102 BMA00-B1P
103 1R8-B1V 104 1R8-B1V
105 BMA10-B1P 106 BBS1-B1P
107 BBS0-B1P 108 BRAS-B1N
109 BWE-B1N 110 MCS2-B1N
111 1R8-B1V 112 1R8-B1V
113 BCAS-B1N 114 MODT2-B1P
115 MCS3-B1N 116 BMA13-B1P
117 1R8-B1V 118 1R8-B1V
119 MODT3-B1P 120 NC
121 GND 122 GND
123 BDQ37-B1P 124 BDQ36-B1P
125 BDQ32-B1P 126 BDQ33-B1P
127 GND 128 GND
129 BDQS4-B1N 130 BDM4-B1P
131 BDQS4-B1P 132 GND
