Appendices Appendix C Pin Assignments
C-6 [CONFIDENTIAL] Qosmio G50 Maintenance Manual (960-683)
Table C-2 Memory B connector (200-pin) (3/3)
Pin No. Signal Name Pin No. Signal Name
133 GND 134 BDQ35-B1P
135 BDQ34-B1P 136 BDQ38-B1P
137 BDQ39-B1P 138 GND
139 GND 140 BDQ41-B1P
141 BDQ45-B1P 142 BDQ40-B1P
143 BDQ44-B1P 144 GND
145 GND 146 BDQS5-B1N
147 BDM5-B1P 148 BDQS5-B1P
149 GND 150 GND
151 BDQ46-B1P 152 BDQ43-B1P
153 BDQ47-B1P 154 BDQ42-B1P
155 GND 156 GND
157 BDQ53-B1P 158 BDQ49-B1P
159 BDQ52-B1P 160 BDQ48-B1P
161 GND 162 GND
163
NC
164
XMCK4-B1P
165
GND
166
XMCK4-B1N
167 BDQS6-B1N 168 GND
169 BDQS6-B1P 170 BDM6-B1P
171 GND 172 GND
173 BDQ54-B1P 174 BDQ50-B1P
175 BDQ51-B1P 176 BDQ55-B1P
177 GND 178 GND
179 BDQ56-B1P 180 BDQ61-B1P
181 BDQ57-B1P 182 BDQ60-B1P
183 GND 184 GND
185 BDM7-B1P 186 BDQS7-B1N
187 GND 188 BDQS7-B1P
189 BDQ62-B1P 190 GND
191 BDQ63-B1P 192 BDQ59-B1P
193 GND 194 BDQ58-B1P
195 SMBDT1-P3P 196 GND
197 SMBCK1-P3P 198 GND
199 P3V 200 GND
1T GND 2T GND
