Appendix C Pin Assignments Appendices
Qosmio G50 Maintenance Manual (960-683) [CONFIDENTIAL] C-7
C.3 CN1900 1
st
HDD SATA interface connector (23-pin)
Table C-3 1
st
HDD SATA interface connector (23-pin)
Pin No. Signal Name Pin No. Signal Name
S1 GND S2 ZSATT0-P1P
S3 ZSATT0-P1N S4 GND
S5 ZSATR0-P1N S6 ZSATR0-P1P
S7 GND
P1 P3V P2 P3V
P3 P3V P4 GND
P5 GND P6 GND
P7 P5V P8 P5V
P9 P5V P10 GND
P11 NC P12 GND
P13 NC P14 NC
P15 NC
C.4 CN1910 ODD SATA interface connector (13-pin)
Table C-4 ODD SATA interface connector (23-pin)
Pin No. Signal Name Pin No. Signal Name
S1 GND S2 ZSATT1-P1P
S3 ZSATT1-P1N S4 GND
S5 ZSATR1-P1N S6 ZSATR1-P1P
S7 GND
P1 P3V P2 P5V
P3 P5V P4 NC
P5 GND P6 GND
