Toshiba TOSVERT VF-nC3 User Manual

E6581595
F-23
6
Load reduction (current reduction) by carrier frequency and ambient temperature
[Three phase 200 V class]
VFNC3
Ambient
temperature
Carrier frequency
2 - 4 kHz 5 - 12 kHz 13 - 16 kHz
2001P
60C or less
0.7 A 0.7 A 0.7 A
2002P
50C or less
1.4 A 1.4 A 1.4 A
Above 50  60C
1.2 A 1.2 A 1.2 A
2004P
50C or less
2.4 A 2.4 A 2.4 A
Above 50  60C
2.1 A 2.1 A 2.1 A
2007P
40C or less
4.2 A 3.6 A 3.0 A
Above 40  50C
4.2 A 3.2 A 2.8 A
Above 50  60C
3.7 A 3.2 A 2.8 A
2015P
40C or less
7.5 A 7.5 A 7.1 A
Above 40  60C
7.5 A 7.1 A 7.1 A
2022P
40C or less
10.0 A 8.5 A 7.5 A
Above 40  60C
10.0 A 7.5 A 7.5 A
2037P
50C or less
16.7 A 14.0 A 14.0 A
Above 50  60C
16.2 A 13.8 A 12.8 A
[Single phase 200 V class]
VFNC3S
Ambient
temperature
Carrier frequency
2 - 4 kHz 5 - 12 kHz 13 - 16 kHz
2001PL
60C or less
0.7 A 0.7 A 0.7 A
2002PL
50C or less
1.4 A 1.4 A 1.4 A
Above 50  60C
1.2 A 1.0 A 1.0 A
2004PL
50C or less
2.4 A 2.4 A 2.4 A
Above 50  60C
2.0 A 1.8 A 1.8 A
2007PL
50C or less
4.2 A 3.2 A 2.8 A
Above 50  60C
3.6 A 2.5 A 2.2 A
2015PL
40C or less
7.5 A 7.5 A 7.1 A
Above 40  50C
7.5 A 7.1 A 7.1 A
Above 50  60C
7.1 A 7.1 A 6.6 A
2022PL
40C or less
10.0 A 9.1 A 8.0 A
Above 40  50C
10.0 A 7.5 A 7.5 A
Above 50  60C
7.5 A 7.5 A 7.0 A
[Single phase 100 V class]
VFNC3S
Ambient
temperature
Carrier frequency
2 - 4 kHz 5 - 12 kHz 13 - 16 kHz
1001P
60C or less
0.7 A 0.7 A 0.7 A
1002P
50C or less
1.4 A 1.4 A 1.4 A
Above 50  60C
1.2 A 1.0 A 1.0 A
1004P
50C or less
2.4 A 2.4 A 2.4 A
Above 50  60C
2.0 A 1.8 A 1.8 A
1007P
60C or less
4.2 A 4.0 A 4.0 A
Note 1: : Inverter rated output current (Carrier frequency 4 kHz or less, ambient temperature 40C or less )
Note 2: When ambient temperature is above 40C, use after remove the caution label on the top of the inverter.
The current value on the table is the value when the inverter is general installed and with top caution label
for 40C or less, without top caution label for above 40C.

Toshiba TOSVERT VF-nC3 Specifications

General

Model	VF-nC3
Category	Inverter
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, sensorless vector control
Overload Capacity	150% for 60 seconds
Input Frequency	50/60 Hz
Enclosure Rating	IP20
Input Voltage	200-240V AC
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Ambient Temperature	-10°C to +50°C
Communication	Modbus RTU
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Braking Unit	Built-in braking transistor (for models up to 22kW), External braking resistor required
