Toshiba TOSVERT VF-nC3 User Manual

E6581595
F-49
6
[Parameter setting]
Title
Function Adjustment range Default setting

Detection of output short-circuit at
start-up
0: Each time (standard pulse)
1: Only one time after power on
(standard pulse)
2: Each time (short pulse)
3: Only one time after power on
(short pulse)
0
6.16.9 Over-torque trip
 : Over-torque trip/alarm selection
 : Over-torque detection level
 : Over-torque detection time
 : Over-torque detection hysteresis
 Function
If the torque value exceeds the value set at  and doesn’t return below -
for a time that exceeds the value set at , tripping or output alarm will be activated.
 is displayed in the event of a trip.
=: .......... No tripping (FL relay deactivated).
An over-torque alarm can be put out by setting the output terminal function selection
parameter.
=: .......... The inverter is tripped (FL relay activated) only after a torque exceeding the -
specified level has been detected for more than the -specified time.
[Parameter setting]
Title Function Adjustment range Default setting

Over-torque trip/alarm selection
0: Alarm only
1: Tripping
0

Over-torque detection level
0 (disabled),
1-200(%)
150

Over-torque detection time 0.0-10.0 (s) Note 0.5

Over-torque detection hysteresis 0-100 (%) 10
Note: = 0.0 seconds is the shortest time detected on control.

Toshiba TOSVERT VF-nC3 Specifications

General

Model	VF-nC3
Category	Inverter
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, sensorless vector control
Overload Capacity	150% for 60 seconds
Input Frequency	50/60 Hz
Enclosure Rating	IP20
Input Voltage	200-240V AC
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Ambient Temperature	-10°C to +50°C
Communication	Modbus RTU
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Braking Unit	Built-in braking transistor (for models up to 22kW), External braking resistor required
