E6581595
F-63
6
(2) Parameter writer (Type: RKP002Z)
Communication cable (Type: CAB0011 (1m), CAB0013 (3m), CAB0015 (5m))
(3) Extension panel (Type: RKP007Z)
Communication cable (Type: CAB0071 (1m), CAB0073 (3m), CAB0075 (5m))
 Settings for run/stop via communication
Title Function
Adjustment
range
Standard
defaults
Setting example

Command mode selection
～
(panel)
 (RS485
communications)
 Settings for speed command via communication
Title Function
Adjustment
range
Standard
defaults
Setting example

Frequency setting mode
selection
 ~  (Setting dial)
 (RS485
communications)
 Communication function parameters (2-wire RS485 communication)
Communication speed, parity, inverter number, and communication error trip time settings can be changed
via panel operations or communication.
[Parameter setting]
Title Function Adjustment range Default setting

Baud rate
3: 9600bps
4: 19200bps
5: 38400bps
4

Parity
0: NON (No parity)
1: EVEN (Even parity)
2: ODD (Odd parity)
1

Inverter number 0-247 0

Communication time-out time *1
0: Disabled (*)
0.1-100.0 (s)
0.0

Communication time-out action *2
0: Alarm only
1: Trip (Coast stop)
2: Trip (Deceleration stop)
0

Communication waiting time 0.00-2.00 (s) 0.00

Communication time-out detection
condition
0: Valid at any time
1: Communication selection of
fmod or cmod
2: 1  during operation
1

Selection of communication
protocol
0: Toshiba inverter protocol
1: ModbusRTU protocol
0
*1: Disabled .......... Indicates that the inverter will not be tripped even if a communication error occurs.
*2: Trip .................. The inverter trips when a communication time-over occurs.
In this case a trip information  flashes on and off on the operation panel.
Alarm ................ When a communication time-over occurs, an alarm can be output from the output terminal.
Output terminal function: 78 (RS485 communication error) or 79 (RS485 communication
error reverse)
