Toshiba TOSVERT VF-nC3 User Manual

E6581595
H-7
8
(Continued)
Item displayed
Panel
operated
LED
display
Communic
ation No.
Description
Input terminal
a }}i}i
FE06
The ON/OFF statuses of the control input
terminals (F, R, S1, S2, VI) are displayed in bits.
ON: 
OFF: 
Output terminal
0 }i
FE07
The ON/OFF status of each of the control signal
output terminals (OUT and FL) at the occurrence
of a trip is displayed in bits.
ON: 
OFF: 
Logic input
terminals setting

FD31
Logic setting by  is displayed.
: Sink logic (External power supply)
: Source logic
: Sink logic (Internal power supply)
CPU1 version

FE08 The version of the CPU1 is displayed.
CPU2 version

FE73 The version of the CPU2 is displayed.
Past trip 1
 
FE10 Past trip 1 (displayed alternately)
Past trip 2
 
FE11 Past trip 2 (displayed alternately)
Past trip 3
 
FE12 Past trip 3 (displayed alternately)
Past trip 4
 
FE13 Past trip 4 (displayed alternately)
(Continued overleaf)
Refer to page H-8 for notes.
Note 5
a
}}i}i
VI
S2
F
R
S1
0
}i
FL
OUT
Note 4
Note 6
Note 6
Note 6
Note 6

Toshiba TOSVERT VF-nC3 Specifications

General

Model	VF-nC3
Category	Inverter
Output Frequency Range	0.1 to 400 Hz
Control Method	V/f control, sensorless vector control
Overload Capacity	150% for 60 seconds
Input Frequency	50/60 Hz
Enclosure Rating	IP20
Input Voltage	200-240V AC
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Ambient Temperature	-10°C to +50°C
Communication	Modbus RTU
Cooling Method	Fan Cooled
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000m
Braking Unit	Built-in braking transistor (for models up to 22kW), External braking resistor required
