E6581595
I-8
9
Table 2 AIC, Fuse and Wire sizes
Inverter model
Maximum
voltage
(V)
Input
withstand
rating (kA)
(1)
Output
interrupt
rating (kA)
(2)
Branch circuit
protection
Rating
(A)
Wire sizes of
power circuit
Earth Cable
Y
X Z1 Z2
VFNC3-2001P 240 5 5 Class CC 3 AWG 14 AWG 14
VFNC3-2002P 240 5 5
Class CC 5
AWG 14 AWG 14
VFNC3-2004P 240 5 5
Class CC 7
AWG 14 AWG 14
VFNC3-2007P 240 5 5
Class J 15
AWG 14 AWG 14
VFNC3-2015P 240 5 5
Class J 25
AWG 14 AWG 14
VFNC3-2022P 240 5 5
Class J 25
AWG 12 AWG 14
VFNC3-2037P 240 5 5
Class J 45
AWG 10 AWG 10
VFNC3S-2001PL 240 1 5 Class CC 5 AWG 14 AWG 14
VFNC3S-2002PL 240 1 5
Class CC 7
AWG 14 AWG 14
VFNC3S-2004PL 240 1 5
Class J 15
AWG 14 AWG 14
VFNC3S-2007PL 240 1 5
Class J 25
AWG 14 AWG 14
VFNC3S-2015PL 240 1 5
Class J 40
AWG 10 AWG 12
VFNC3S-2022PL 240 1 5
Class J 45
AWG 10 AWG 10
VFNC3S-1001P 120 1 5 Class CC 8 AWG 14 AWG 14
VFNC3S-1002P 120 1 5
Class J 15
AWG 14 AWG 14
VFNC3S-1004P 120 1 5
Class J 25
AWG 14 AWG 14
VFNC3S-1007P 120 1 5
Class J 40
AWG 10 AWG 12
Suitable for use on a circuit capable of delivering not more than___X___rms symmetrical kilo Amperes,___Y___Volts
maximum, when protected by___Z1___with a maximum rating of___Z2___.
(1) Input withstand rating is that for which the product has been designed thermally. Installation on a supply greater than
this level will require additional inductance to satisfy this level.
(2) Output interrupt rating relies on Integral solid state short circuit protection. This does not provide branch circuit
protection. Branch circuit protection must be provided in accordance with the National Electrical Code and any
additional local codes. This is dependant on the type of installation.
9.2.5 Overload protection
VF-nC3 has overload protection.
Over current rating: 150%-1min. , 200%-0.5sec.
Refer to the nameplate for the rated current.
